Band: opinion spread · Dot: weighted average
Strong for the format and not seriously disputed. Reviewers drive hard in-ears and many full-size headphones from a phone, and two owners report reaching loud levels on demanding planars and the HD 800 S from the balanced output. The reservations are specific: the 3.5 mm output has no real advantage over cheaper dongles, the balanced output impedance of about 3 Ω is higher than some low-impedance multi-driver in-ears like, and the very hardest loads still want a desktop amp.
“Despite how hard MSE is to drive, W4 keeps up nicely at around 70/100 in high gain.”
Guy Lerner, The Headphone List
“you’ll be able to get 114 dB/SPL from the W4 into the HD800S”
Torq, forum.headphones.com
“it would be 9.6/10 on anything >40 ohm and 2/10 on my Andromeda, Ara, Variations, and Solis II”
BlueEmperor, Head-Fi, on the balanced output impedance
Measured
L&P rates the W4 at 110 mW (3.5 mm) and 420 mW (4.4 mm) into 32 Ω at under 0.01% THD+N. L7 Audio Lab measured 4.08 Vrms from the balanced output into an unloaded analyser input. ClieOS, an owner with a meter and a 47 Ω dummy load, measured a maximum of 0.68 V (about 59 mW) single-ended and 1.31 V (about 195 mW) balanced at high gain, and output impedance of 1.55 Ω single-ended and 3.14 Ω balanced — "not so high to be any real concern," in his words, but higher than he expected. L&P's own test on an iPhone's Lightning port (about 3.6 V) reached full volume, 2 Vrms into 32 Ω, while drawing 830 mW from the phone.
