Band: opinion spread · Dot: weighted average
Sources split on the same shelf. The large majority — most written reviews, nearly every Head-Fi and Reddit owner, and the video reviewers — hear a punchy, textured mid-bass with more control than the graph suggests and note that it is mid- and upper-bass, not sub-bass, that is boosted. A smaller but heavier-hitting camp, led by the measurement-minded ranking critics, hears the same shelf as bloom that runs into the lower mids. Both agree the sub-bass is only moderate.
Measured
Twenty-six IEC-711-class rigs agree to within about 1 dB below 300 Hz: relative to 500 Hz the shelf sits at +7.7 dB (20 Hz), +8.5 dB (40–60 Hz), +7.4 dB (100 Hz), and is still +4.5 dB at 200 Hz and +2.1 dB at 300 Hz. Against Harman IE 2019 that is 1 dB less at 20 Hz but +3 dB at 100 Hz and +4 dB from 150 to 250 Hz — a mid-bass hump, not a sub-bass shelf. Switch 1 lifts the whole band below 1 kHz by a flat +2.4 dB and nothing else; the 5128 rig reads the same shape.
vs. listeners — The graphs settle what is there, not how it lands: the +4 dB at 150–250 Hz is the weight the 'controlled' camp praises and the 'bloom' the critics object to. Tips and insertion depth move this region by under half a decibel on listener's rig, so the split is not a seal artefact; a high-impedance source (a phone, a Bluetooth adapter) does tilt it darker by 2–4 dB, which is where some of the 'muddy out of the box' reports come from.
“However, due to the clarity and the way the IEMs handles these notes, they are not overly bloated or muddy.”
SenyorC, Acho Reviews
“Overly extended bass that bleeds into the mid-range (very warm).”
Nymz, via IEMRanking
