Band: opinion spread · Dot: weighted average
Sources split by output and load. The majority — Headfonics, Headfonia, Android Central, Audiophile Heaven, Major HiFi, Home Studio Basics, ATechReviews — find the balanced jack ample for any IEM and most headphones: Major HiFi drove FiiO's 350-ohm FT3 with headroom, Android Central the planar FT5, Audiophile Heaven even a HE1000SE to high volume, and AudioTOP measured 334 mW, well above most dongles. The other camp meets its limit: an ASR owner found the single-ended jack short of headroom for an HD 580 with EQ, LesModio says the HD 600 plays 'without too much headroom', a Head-Fi owner heard a HE400se get only slightly louder than on the old BTR5, and another runs 600-ohm Sennheisers at maximum. Pragmatic Audio rates it a little behind the Qudelix 5K on output. Audiophile Heaven itself excludes the HD 660S2 and HD 800S.
Measured
FiiO's table (USB input, THD+N <1%): single-ended ≥165 + 165 mW into 16 Ω and ≥125 + 125 mW into 32 Ω, 2 Vrms; balanced ≥270 + 270 mW into 16 Ω, ≥340 + 340 mW into 32 Ω and ≥50 + 50 mW into 300 Ω, 3.2 Vrms. AudioTOP's Audio Precision bench measured 334 mW maximum from the balanced jack, against 240 mW for the BTR5 generations and a dongle median of about 255 mW. On USB power, a Head-Fi owner's USB meter read a flat 3 W draw in PC mode on launch firmware.
“首先是极限输出功率,平衡口334毫瓦,比前两代的240毫瓦有明显的提升。”
AudioTOP (Chinese: “first, maximum output power — 334 mW balanced, a clear step up from the 240 mW of the two previous generations”)
“While it falls slightly short in app customization and power output”
Jerome O'Flaherty · Pragmatic Audio
