Band: opinion spread · Dot: weighted average
Sources split, and the split follows the load. Reviewers using IEMs or high-impedance dynamic headphones — Sennheiser HD 600s, a Beyerdynamic DT 1990, an Audeze LCD-X at moderate levels — found it plenty loud. Everyone who measured into headphone-like loads, and the reviewers who tried hard planars, 600-ohm Beyerdynamics or low-impedance cans at volume, found its output stage clipping or audibly straining well before 2 volts. Owners who use it as a line-level DAC are told to stop just short of full volume.
Measured
ASR measured 26 mW into 32 ohms and 12 mW into 300 ohms at clipping. Stereophile found the output clipping at −3 dBFS into 300 and 50 ohms, needing −6 dB into 30 ohms and −12 dB into 10 ohms; Audiophile Style found it clean into 50 ohms only 5 dB below full volume (1.21 Vrms), with the negative half of the waveform clipping first. Archimago's retail unit clipped at 100% volume even unloaded. AudioQuest rates the output at 2.1 V into 10k ohms or more and 16 ohms as the minimum headphone load.
vs. listeners — The 2.1-volt rating is real into a line-level input, which is how AudioQuest specifies it; into headphones the limit is current, not voltage. That is why listeners on sensitive IEMs or 300-ohm Sennheisers rarely notice anything, while the same unit audibly strains on a low-impedance planar.
“AudioQuest claims an output of 2.1v which translates in reality into the ability to drive any earphone to the point where it explodes and most headphones won’t be a struggle either.”
AVForums
“Unfortunately it then proceeds to deliver a highly distorting product that has little ability to drive low impedance headphones.”
Amir · Audio Science Review
