Band: opinion spread · Dot: weighted average
Sources split three ways on the same shelf. The larger camp hears a big but controlled, snappy sub-woofer with little distortion; a nearly equal camp hears bloat that reaches into the lower mids and needs EQ; and one high-weight outlier reports the stock quantity itself as underwhelming — a report its own commenters attribute to fit. Seal, tips and source impedance move this set more than most.
Measured
Fourteen squig.link rigs agree to within ±0.5 dB below 1 kHz: relative to 500 Hz the shelf sits at +13.6 dB (20 Hz), +11.9 dB (60 Hz), +9.4 dB (100 Hz), and is still +5.1 dB at 200 Hz and +2.6 dB at 300 Hz — it only flattens around 500 Hz. Against Harman IE 2019 that is a further +4–5 dB from 40 to 200 Hz on top of Harman's own shelf.
vs. listeners — The graphs settle the quantity, not the verdict: the shelf that the 'controlled' camp hears as weight is the same 200–400 Hz tail the 'bloat' camp hears as mud. The lone 'not that bassy' report is not on any rig; the Legato is a shallow, vented fit, and a broken seal drops the sub-bass first.
“Still, the Legato maintains remarkable control over its large amount of bass. The bass is generally snappy and rarely overstays its welcome.”
o0genesis0o, Head-Fi
“It has a 15 dB bass shelf that reaches to 500Hz, which is deep into the mid-range. Because of this, there is definitely many opportunities for muddy mid-ranges, and the Legato is something I classify as dirty bass.”
Antdroid, Audio Discourse
“I don’t consider this Legato to have aspiringly interesting or prominent bass quantity. It sounds enjoyable still, no doubt. But the quantity without bass boosting is shoulder-shrug worthy.”
Michael, Headfonics
